Kubota M7-163
|
|
| Production | |
| Manufacturer | Kubota |
| Utility tractor | |
| Built in Bierne, France | |
| Kubota M7-163 Engine | |
| Kubota 6.1L 4-cyl diesel | |
| Fuel tank | 87.2 gal 330.1 L |
| Exhaust fluid (DEF) | 10 gal 37.9 L |
 Engine details ... | |
| Kubota M7-163 Transmissions | |
| 30-speed six-speed power shift | |
| infinitely-variable transmission | |
 Transmission details ... |
| Kubota M7-163 Power | |
| Engine (gross) | 150 hp 111.9 kW |
| Engine (max) | 170 hp 126.8 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Cab standard with air-conditioning. |
| Photos | |
| No photos of the Kubota M7-163 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| closed-center load-sensing OptOptional | |
| Valves | 3 to 6 |
| Pump flow | 21.1 gpm (open) 79.9 lpm |
| 29.1 gpm (closed) 110.1 lpm | |
| Tractor hitch | |
| Rear Type | III |
| Control | lower-link draft sensing |
| Rear lift (at ends) | 20723 lbs 9399 kg |
| Front lift | 7717 lbs 3500 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Engine RPM | 540E@1608 |
| 540@2005 | |
| 1000E@1600 | |
| 1000@1995 | |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Dimensions & Tires | |
| Wheelbase | 107.1 inches 272 cm |
| Weight | 16204 lbs 7350 kg |
| Front tire | 540/65R28 |
| Rear tire | 650/65R38 |
 Full dimensions and tires ... | |
| Kubota M7-163 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 150 |
| Battery CCA | 1000 |
| Battery volts | 12 |
| Battery AH | 170 |
| References | |
 | |
| M7003 Series published in 2020, by Kubota |
