John Deere 6010SE



No photo available
1998 - 2003
6010SE Series
Utility tractor
Series map:
6010SE
6110SE
55.9kw
59.7kw
Production
ManufacturerJohn Deere
Utility tractor
John Deere 6010SE Engine
John Deere 4.5L 4-cyl diesel
Engine details ...
John Deere 6010SE Transmissions
12-speed synchronized
16-speed power shuttle
16-speed four-speed power shift
Transmission details ...
John Deere 6010SE Power
Engine (net)75 hp
55.9 kW
Mechanical
Two- or four-wheel drive
Differential lockelectro-hydraulic rear
Power steering
Hydraulic wet disc brakes
Trailer brakeshydraulic OptOptional
 pneumatic OptOptional
Cab standard with heat. Optional air-conditioning.
Photos
No photos of the John Deere 6010SE are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel43.6 gal
165.0 L
 30.6 gal (LP Cab)
115.8 L
Hydraulic system14.5 gal
54.9 L
Hydraulics
Typeload sensing
Capacity14.5 gal
54.9 L
Pressure2901 psi
200.0 bar
Valves4 OptOptional
Pump flow14.3 gpm
54.1 lpm
Tractor hitch
Rear TypeII
Controlelectronic lower-link draft sensing
Rear lift8970 lbs
4068 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540
 540/1000
 540/540E/1000
Engine RPM540@2124
 1000@2208
 540E@1684
Front PTOindependent
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Engine RPM1000@2185
Dimensions & Tires
Wheelbase94.5 inches
240 cm
Weight8514 lbs
3861 kg
Front tire12.4R24
Rear tire16.9R30
Full dimensions and tires ...
6010SE Serial Numbers
Location:Serial number plate on the right side of the tractor’s frame.
Electrical
Groundnegative
Charging systemalternator
Charging amps90
Battery volts12
Battery AH110
References
6010SE references literature
6010 SE Series Tractors published in 2002, by John Deere
