Fendt 415 Vario

Fendt 415 Vario tractor photo
2006 - 2012
400 Vario Series
Row-Crop tractor
Series map:
414 Vario
415 Vario
ManufacturerFendt (a part of AGCO)
Row-Crop tractor
Fendt 415 Vario Engine
Deutz 4.0L 4-cyl diesel
Fuel tank64.7 gal
244.9 L
Engine details ...
Fendt 415 Vario Transmission
continuously variable transmission
Transmission details ...
Fendt 415 Vario Power
Engine (gross)151.5 hp
113.0 kW
Engine (net)138.1 hp
103.0 kW
Engine (max)158.2 hp
118.0 kW
Four-wheel drive
Power steering
Wet disc brakes
Cab standard with heat. Air-conditioning optional.
Typeload sensing
Pressure2900 psi
200.0 bar
Pump flow19.8 gpm
74.9 lpm
 29.1 gpmOptOptional
110.1 lpm
Tractor hitch
Rear TypeIII/II
Rear lift16424 lbs
7449 kg
Front lift6834 lbs
3099 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540/540E/1000
Front PTOindependent OptOptional
Front RPM540
Dimensions & Tires
Wheelbase95.2 inches
241 cm
Weight11949 lbs
5420 kg
Front tire540/65R24
Rear tire600/65R38
Full dimensions and tires ...
Charging systemalternator
Charging amps150
Charging volts14
Battery volts12
Battery AH90
415 Vario references literature
Fendt 400 Vario published in 2006
Fendt 400 Vario published in 2008
Fendt 400 Vario published in 2010
