Fendt 413 Vario

Fendt 413 Vario tractor photo
2006 - 2012
400 Vario Series
Row-Crop tractor
Farmer 412 Vario
Series:412 Vario413 Vario414 Vario
Manufacturer:Fendt (a part of AGCO)
Type:Row-Crop tractor
Fendt 413 Vario Power
Engine (gross):131.4 hp
98.0 kW
Engine (net):118 hp
88.0 kW
Engine (max):138.1 hp
103.0 kW
Fendt 413 Vario Engine
Deutz 4.0L 4-cyl diesel
Fuel tank:64.7 gal
244.9 L
Engine details ...
Chassis:4x4 MFWD 4WD
Brakes:wet disc
Cab:Cab standard with heat. Air-conditioning optional.
Transmission:continuously variable transmission
Transmission details ...
No photos of the Fendt 413 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Type:load sensing
Pressure:2900 psi
200.0 bar
Pump flow:19.8 gpm
74.9 lpm
 29.1 gpm
110.1 lpm *Optional
Tractor hitch
Rear Type:III/II
Rear lift:16424 lbs
7449 kg
Front lift:6834 lbs
3099 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/540E/1000
Front PTO:independent*Optional
Front RPM:540
Dimensions & Tires
Wheelbase:95.2 inches
241 cm
Weight:11949 lbs
5420 kg
Front tire:540/65R24
Rear tire:600/65R38
Full dimensions and tires ...
Charging system:alternator
Charging amps:150
Charging volts:14
Battery volts:12
Battery AH:90
