Fendt 313 Vario
| 2012 - 2022 |
|
300 Vario Series | Utility tractor |
|
Production |
Manufacturer: | Fendt (a part of AGCO)
|
Type: | Utility tractor
|
Fendt 313 Vario Power |
Engine (gross): | 120.7 hp 90.0 kW
|
Engine (max): | 131.4 hp 98.0 kW
|
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Differential lock: | automatic front and rear differential lock
|
Steering: | power
|
Brakes: | wet disc
|
Trailer brakes: | hydraulic
|
Cab: | VisioPlus Cab standard with air-conditioning and suspension. Optional pneumatic cab suspension (Profi/Profi+).
|
Transmission: | continuously variable transmission
|
Transmission details ... |
Photos |
No photos of the Fendt 313 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Type: | open center
|
| closed center*Optional
|
Pressure: | 2900 psi 200.0 bar
|
Rear valves: | 2 to 4
|
Front valves: | 1*Optional
|
Pump flow: | 22.2 gpm 84.0 lpm
|
| 29.1 gpm 110.1 lpm (variable flow)
|
Tractor hitch |
Rear lift: | 13140 lbs 5960 kg
|
Front lift: | 6900 lbs 3129 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Rear RPM: | 540/540E/1000
|
Front PTO: | independent*Optional
|
Front RPM: | 1000
|
Electrical |
Ground: | negative
|
Charging system: | alternator
|
Battery volts: | 12
|
Page information |
Last update: | July 16, 2021
|
Copyright: | Copyright 2021 TractorData LLC
|
Contact: | Peter@TractorData.com
|
