Fendt 312 Vario


Fendt 312 Vario tractor photo
2006 - 2021
Model year
300 Vario Series
Series:311 Vario312 Vario313 Vario
Production
Manufacturer:Fendt (a part of AGCO)
Fendt 312 Vario Power
Engine (net):108.6 hp
81.0 kW
Fendt 312 Vario Engine
Deutz 4.0L 4-cyl diesel
Fuel tank:51.5 gal
194.9 L
Exhaust fluid (DEF):5.3 gal
20.1 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Cab standard with heat. Air-conditioning optional.
Transmission:continuously variable transmission
Transmission details ...
Photos
No photos of the Fendt 312 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:open center
Pressure:2900 psi
200.0 bar
Pump flow:21.9 gpm
82.9 lpm
Tractor hitch
Rear lift:13399 lbs
6077 kg
Front lift:6789 lbs
3079 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/540E/1000
Front PTO:independent*Optional
Front RPM:540
 1000
Dimensions & Tires
Wheelbase:92.5 inches
234 cm
Weight:9811 lbs
4450 kg
Front tire:480/65R24
Rear tire:540/65R38
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:150
Charging volts:14
Battery volts:12
Battery AH:90
