Fendt 310 Vario
| | 2006 - 2019 |
|
| 300 Vario Series |
|
| Production |
| Manufacturer: | Fendt (a part of AGCO)
|
| Fendt 310 Vario Power |
| Engine (net): | 88.5 hp
66.0 kW
|
| Mechanical |
| Chassis: | 4x2 2WD
|
| | 4x4 MFWD 4WD
|
| Steering: | power
|
| 2WD Brakes: | drum
|
| 4WD Brakes: | wet disc
|
| Cab: | Cab standard with heat. Air-conditioning optional.
|
| Transmission: | continuously variable transmission
|
 Transmission details ... |
| Photos |
| No photos of the Fendt 310 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2900 psi
200.0 bar
|
| Valves: | 2 to 4
|
| Pump flow: | 20.6 gpm
78.0 lpm
|
| Tractor hitch |
| Rear lift: | 11865 lbs
5381 kg
|
| Front lift: | 6607 lbs
2996 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 540/540E/1000
|
| Front PTO: | independent*Optional
|
| Front RPM: | 540
|
| | 1000
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Charging amps: | 143
|
| Charging volts: | 14
|
| Battery volts: | 12
|
| Battery AH: | 90
|
| Page information |
| Last update: | November 4, 2020
|
| Copyright: | Copyright 2020 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2020 - TractorData™. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
Attachment details ...
