Massey Ferguson 8S.225
|
|
| Production | |
| Manufacturer | Massey Ferguson (a part of AGCO) |
| Row-Crop tractor | |
| Massey Ferguson 8S.225 Engine | |
| AGCO Power 7.4L 6-cyl diesel | |
| Fuel tank | 121.5 gal 459.9 L |
| 132 gal (Dyna-VT) 499.6 L | |
| Exhaust fluid (DEF) | 11.4 gal 43.1 L |
 Engine details ... | |
| Massey Ferguson 8S.225 Transmissions | |
| 28-speed seven-speed power shift | |
| continuously-variable transmission | |
 Transmission details ... |
| Massey Ferguson 8S.225 Power | |
| Engine | 221.3 hp 165.0 kW |
| PTO (claimed) | 195.8 hp 146.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | automatic front and rear |
| Power steering | |
| Trailer brakes | pneumatic |
| hydraulic OptOptional | |
| Cab standard with air-conditioning. | |
| Hydraulics | |
| Type | closed center load-sensing |
| Pressure | 2901 psi 200.0 bar |
| Rear valves | 5 OptOptional |
| Front valves | 2 OptOptional |
| Pump flow | 39.6 gpm 149.9 lpm |
| 54.2 gpmOptOptional 205.1 lpm | |
| Tractor hitch | |
| Rear Type | III |
| Control | position and draft control |
| Rear lift (at ends) | 22046 lbs 10000 kg |
| Front lift | 10582 lbs 4799 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 (1.375) |
| 1000 (1.75) | |
| Engine RPM | 540@1867 |
| 540E@1499 | |
| 1000@1903 | |
| 1000E@1528 | |
| Front PTO | independent |
| Front PTO Type | 1000 |
| Engine RPM | 1000@1920 |
| Dimensions & Tires | |
| Wheelbase | 120.1 inches 305 cm |
| Weight | 19180 to 22046 pounds |
| Front tire | 540/65R30 |
| Rear tire | 650/65R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MF 8S published in 2020, by Massey Ferguson | |
| MF 8S published in 2022, by Massey Ferguson | |
| MF 8S Series published in 2023, by Massey Ferguson |
