Deutz-Fahr 4080E
|
|
| Production | |
| Manufacturer | Deutz-Fahr |
| Utility tractor | |
| Deutz-Fahr 4080E Engine | |
| SDF 2.9L 3-cyl diesel | |
| Fuel tank | 19.8 gal 74.9 L |
 Engine details ... | |
| Deutz-Fahr 4080E Transmissions | |
| 12-speed gear | |
| 8-speed partially synchronized | |
| 15-speed partially synchronized | |
 Transmission details ... |
| Deutz-Fahr 4080E Power | |
| Engine (gross) | 74.3 hp 55.4 kW |
| Mechanical | |
| Two- or four-wheel drive | |
| Differential lock | mechanical |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
 | |
 Deutz-Fahr 4080E photos... | |
| Hydraulics | |
| Type | open center |
| Valves | 1 to 3 |
| Pump flow | 11.1 gpm 42.0 lpm |
| 13.2 gpmOptOptional 50.0 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift | 5512 lbs 2500 kg |
| 7717 lbsOptOptional 3500 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 |
| 540/540E OptOptional | |
| 540/540E/1000 OptOptional | |
| Dimensions & Tires | |
| 2WD Wheelbase | 85.3 inches 216 cm |
| 4WD Wheelbase | 82.7 inches 210 cm |
| Weight | 6173 to 6614 pounds |
| Front tire | 320/85R20 |
| Rear tire | 420/85R28 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 4E Series published in 2018, by Deutz-Fahr | |
| 4E Series published in 2018, by Deutz-Fahr |
