County 1184
|
|
| Production | |
| Manufacturer | County |
| Four-wheel Drive (4WD) tractor | |
| Variants | |
| FC 1184 | forward-control |
| County 1184 Engine | |
| Ford 6.6L 6-cyl diesel | |
| Fuel tank | 36.9 gal 139.7 L |
 Engine details ... | |
| County 1184 Transmission | |
| 16-speed two-speed power shift | |
 Transmission details ... |
| County 1184 Power | |
| Engine | 120 hp 89.5 kW |
| Mechanical | |
| Drive | 4x4 4WD |
| Differential lock | mechanical front and rear |
| Power steering | |
| Wet disc brakes | |
| Cab standard with heat. | |
| Photos | |
 | |
 County 1184 photos... | |
| Hydraulics | |
| Pressure | 2500 psi 172.4 bar |
| Pump flow | 9.25 gpm 35.0 lpm |
| Steering flow | 4.3 gpm 16.3 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 9300 lbs 4218 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1900 |
| 1000@2060 | |
| Dimensions & Tires | |
| Front tire | 16.9/14-34 |
| Rear tire | 16.9/14-34 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 72 |
| Battery AH | 128 |
| References | |
 | |
| 1184 published in 1988, by County | |
| 1184 TW published by County |
