CaseIH 485 Orchard
|
|
| Production | |
| Manufacturer | CaseIH |
| Orchard/Vineyard tractor | |
| CaseIH 485 Orchard Engine | |
| CaseIH 2.9L 3-cyl diesel | |
 Engine details ... |
| CaseIH 485 Orchard Transmissions | |
| 8-speed synchromesh | |
| 16-speed two-speed power shift | |
 Transmission details ... |
| CaseIH 485 Orchard Power | |
| Engine (gross) | 53 hp 39.5 kW |
| Engine (net) | 50 hp 37.3 kW |
| PTO (claimed) | 42 hp 31.3 kW |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Hydraulic wet disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the CaseIH 485 Orchard are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 18.5 gal 70.0 L |
| Hydraulic system | 9 gal 34.1 L |
| Hydraulics | |
| Capacity | 9 gal 34.1 L |
| Pressure | 2500 psi 172.4 bar |
| Pump flow | 15.9 gpm 60.2 lpm |
| 17 gpmOptOptional 64.3 lpm | |
| Steering flow | 2.5 gpm 9.5 lpm |
| Tractor hitch | |
| Rear Type | II/I |
| Control | position and draft control |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 72.2 inches 183 cm |
| Weight | 4790 lbs 2172 kg |
| Front tire | 9.00x10 |
| Rear tire | 18.4x16.1 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 45 |
| Battery volts | 12 |
| Battery AH | 93 |
| References | |
 | |
| Model 485, 585, 685 Orchard & Vineyard Tractor published in 1985, by CaseIH |
