TYM T264
|
|
| Production | |
| Manufacturer | TYM |
| Compact Utility tractor | |
| TYM T264 Engine | |
| Kukje 1.2L 3-cyl diesel | |
| Fuel tank | 6.6 gal 25.0 L |
 Engine details ... | |
| TYM T264 Transmission | |
| hydrostatic | |
 Transmission details ... |
| TYM T264 Power | |
| Engine (gross) | 24.1 hp 18.0 kW |
| PTO (claimed) | 18.3 hp 13.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. |
| Photos | |
 | |
 TYM T264 photos... | |
| Hydraulics | |
| Type | open center |
| Pump flow | 4.4 gpm 16.7 lpm |
| Total flow | 7.1 gpm 26.9 lpm |
| Steering flow | 2.7 gpm 10.2 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 1503 lbs 681 kg |
| Rear lift (at 24"/610mm) | 1102 lbs 499 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO | independent |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 58.3 inches 148 cm |
| Weight | 1881 lbs 853 kg |
 Full dimensions and tires ... | |
| TYM T264 attachments | |
| 60" mid-mount mower deck | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging amps | 50 |
| Battery volts | 12 |
| References | |
 | |
| T264 Sub-Compact, Series 2 published in 2025, by TYM |
