TYM T234


TYM T234 tractor photo
2015 - 2019
Sub-Compact Utility tractor
Production
ManufacturerTYM
Sub-Compact Utility tractor
TYM T234 Engine
Mitsubishi 1.3L 3-cyl diesel
Fuel tank6.6 gal
25.0 L
Engine details ...
TYM T234 Power
Engine (gross)24.4 hp
18.2 kW
PTO (claimed)18.3 hp
13.6 kW
Mechanical
Power steering
Wet disc brakes
Two-post folding ROPS.
Photos
No photos of the TYM T234 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow4.4 gpm
16.7 lpm
Total flow6.7 gpm
25.4 lpm
Steering flow2.3 gpm
8.7 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)1534 lbs
695 kg
Rear lift (at 24"/610mm)1102 lbs
499 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Mid PTOindependent
Mid PTO Type2000
Dimensions & Tires
Wheelbase58.3 inches
148 cm
Weight1907 lbs
865 kg
Full dimensions and tires ...
TYM T234 attachments
60" mid-mount mower deck
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging amps50
Battery volts12
References
T234 references literature
T194HST, T234HST, T254/T254HST published in 2016, by TYM
T234 published in 2015, by TYM
