CaseIH CS 110


CaseIH CS 110 tractor photo
1997 - 2003
CS Series
Row-Crop tractor
Series map:
CS 110
CS 120
77.3kw
84.6kw
Production
ManufacturerCaseIH
Row-Crop tractor
Built in Saint Valentin, Austria
Variants
9105similar Steyr model
CaseIH CS 110 Engine
Sisu 4.4L 4-cyl diesel
Fuel tank58.1 gal
219.9 L
 79.3 gal*Total capacity with optional 80 liter fuel tank.
300.2 L
Engine details ...
CaseIH CS 110 Transmissions
24-speed four-speed power shift
40-speed creeper
Transmission details ...
CaseIH CS 110 Power
Engine (net)103.6 hp
77.3 kW
PTO (claimed)92.7 hp
69.1 kW
Mechanical
Four-wheel drive
Power steering
Wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the CaseIH CS 110 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Pressure2683 psi
185.0 bar
Pump flow21.1 gpm
79.9 lpm
 30.4 gpmOptOptional
115.1 lpm
Tractor hitch
Rear TypeIII
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540/1000 (1.375)
Engine RPM540@2200
 540E@1680
 1000@2200
 1000E@1600
Front PTO Type1000
Dimensions & Tires
Wheelbase99.6 inches
252 cm
Weight11056 lbs
5015 kg
Front tire540/65R24
Rear tire600/65R38
Full dimensions and tires ...
References
CS 110 references literature
CS110-CS150 published in 1998, by CaseIH
CS110 & CS150 published in 2000, by CaseIH
