John Deere 6145M



John Deere 6145M tractor photo
2015 - 2024
Model year
6M Series
Utility tractor
Series map:
6140M
6145M
6155M
160.0hp
145.0hp
155.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $135,176 in 2020
John Deere 6145M Engine
John Deere 4.5L 4-cyl diesel
Fuel tank71.3 gal
269.9 L
Exhaust fluid (DEF)4.2 gal
15.9 L
Engine details ...
John Deere 6145M Transmissions
16-speed four-speed power shift
24-speed four-speed power shift
infinitely variable transmission (IVT)
Transmission details ...
John Deere 6145M Power
Engine (gross)145 hp
108.1 kW
Engine (max)161 hp
120.1 kW
PTO (claimed)116 hp
86.5 kW
Drawbar (tested)109.6 hp
81.7 kW
PTO (tested)134.2 hp
100.1 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning. AutoTrac ((Optional));JDLink ((Optional))
Photos
No photos of the John Deere 6145M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeclosed center pressure and flow compensated
Rear valves2 to 4
Front valves0 to 3
Pump flow30 gpm
113.6 lpm
Tractor hitch
Rear TypeIIIN
Controlelectronic lower link draft sensing
Rear lift (at ends)11023 lbs*Actual tested lift was 10995 pounds.
5000 kg
 12556 lbs*Optional. Actual tested lift was 12410 pounds.
5695 kg
Front HitchIIIN OptOptional
Front lift9700 lbs
4399 kg
DrawbarCat. 2
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1977
 1000@1972
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Engine RPM1000@1969
Dimensions & Tires
Wheelbase108.9 inches
276 cm
Weight13668 lbs
6199 kg
Front tire540/65R28
Rear tire650/65R38
Full dimensions and tires ...
John Deere 6145M attachments
front-end loader
Attachment details ...
6145M Serial Numbers
Location:Serial number plate on the right side of the main tractor frame.
Electrical
Groundnegative
Charging systemalterntor
Charging amps120
 150 OptOptional
 200 OptOptional
Charging volts14
Battery volts12
Battery AH154
 174 OptOptional
References
6145M references literature
6M Tractors published in 2020, by John Deere
