Tractors > John Deere > 6130M

John Deere 6130M



John Deere 6130M tractor photo
2015 - 2024
Model year
6M Series
Utility tractor
Series map:
6120M
6130M
6140M
140.0hp
150.0hp
160.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Mannheim, Baden-Württemberg, Germany
Original price was $119,812 in 2020
John Deere 6130M Engine
John Deere 4.5L 4-cyl diesel
Fuel tank51.5 gal
194.9 L
Exhaust fluid (DEF)3.4 gal
12.9 L
Engine details ...
John Deere 6130M Transmissions
16-speed four-speed power shift
24-speed four-speed power shift
infinitely variable transmission (IVT)
Transmission details ...
John Deere 6130M Power
Engine (gross)130 hp
96.9 kW
Engine (max)156 hp
116.3 kW
PTO (claimed)101 hp
75.3 kW
Drawbar (tested)94.8 hp
70.7 kW
PTO (tested)119.1 hp
88.8 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesplanetary
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Cab standard with air-conditioning. AutoTrac ((Optional));JDLink ((Optional))
Photos
No photos of the John Deere 6130M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
 closed center PFC OptOptional
Rear valves2 to 4
Front valves0 to 3
Pump flow21.2 gpm (open)
80.2 lpm
 30 gpm (closed)
113.6 lpm
Tractor hitch
Rear TypeII/IIIN
Controlelectronic lower link draft sensing
Rear lift (at ends)11023 lbs
5000 kg
 12556 lbs*Optional. Actual tested lift was 12455 pounds.
5695 kg
Front HitchIIIN OptOptional
Front lift9700 lbs
4399 kg
DrawbarCat. 2
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic wet disc
Rear PTO Type540/1000 (1.375)
Engine RPM540@1977
 1000@1972
Front PTOindependent OptOptional
Clutchelectro-hydraulic wet disc
Front PTO Type1000
Engine RPM1000@1969
Dimensions & Tires
Wheelbase101.6 inches
258 cm
Weight12786 lbs
5799 kg
Front tire540/65R24
Rear tire600/65R38
Full dimensions and tires ...
John Deere 6130M attachments
front-end loader
Attachment details ...
6130M Serial Numbers
Location:Serial number plate on the right side of the main tractor frame.
Electrical
Groundnegative
Charging systemalterntor
Charging amps120
 150 OptOptional
 200 OptOptional
Charging volts14
Battery volts12
Battery AH154
 174 OptOptional
References
6130M references literature
6M Tractors published in 2020, by John Deere
