LS MT573
|
|
| Production | |
| Manufacturer | LS |
| Utility tractor | |
| Variants | |
| MT573C | sync shuttle |
| MT573CPS | power shuttle |
| LS MT573 Engine | |
| LS 2.5L 4-cyl diesel | |
| Fuel tank | 26.4 gal 99.9 L |
 Engine details ... | |
| LS MT573 Transmission | |
| 20-speed synchro shuttle | |
 Transmission details ... |
| LS MT573 Power | |
| Engine (gross) | 73 hp 54.4 kW |
| PTO (claimed) | 62 hp 46.2 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Cab standard with air-conditioning. |
| Photos | |
 | |
 LS MT573 photos... | |
| Hydraulics | |
| Rear valves | 3 |
| Front valves | 3 |
| Pump flow | 13.2 gpm 50.0 lpm |
| Total flow | 19.8 gpm 74.9 lpm |
| Steering flow | 6.6 gpm 25.0 lpm |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 6614 lbs 3000 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/750/1000 |
| Dimensions & Tires | |
| Wheelbase | 84.6 inches 214 cm |
| Weight | 6620 to 6669 pounds |
| Front tire | 11.2-24 |
| Rear tire | 16.9-30 |
 Full dimensions and tires ... | |
| LS MT573 attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Battery volts | 12 |
| References | |
 | |
| MT5 Series published in 2017, by LS | |
| MT5 Series published in 2021, by LS |
