LS XR4150
|
|
| Production | |
| Manufacturer | LS |
| Compact Utility tractor | |
| LS XR4150 Engine | |
| LS 1.9L 3-cyl diesel | |
| ROPS Fuel tank | 10.6 gal 40.1 L |
| Cab Fuel tank | 12.4 gal 46.9 L |
 Engine details ... | |
| LS XR4150 Transmissions | |
| 16-speed synchronized shuttle | |
| hydrostatic | |
 Transmission details ... |
| LS XR4150 Power | |
| Engine (gross) | 50 hp 37.3 kW |
| Hydro PTO (claimed) | 40 hp 29.8 kW |
| Shuttle PTO (claimed) | 43 hp 32.1 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional with available air-conditioning. |
| Photos | |
| No photos of the LS XR4150 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Valves | 2 |
| Pump flow | 8.2 gpm 31.0 lpm |
| Shuttle Total flow | 12.3 gpm 46.6 lpm |
| Hydro Total flow | 13.7 gpm 51.9 lpm |
| Shuttle Steering flow | 4.1 gpm 15.5 lpm |
| Hydro Steering flow | 5.5 gpm 20.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position and draft control |
| Rear lift (at ends) | 2755 lbs 1249 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Mid PTO Type | 2000 |
| Dimensions & Tires | |
| Wheelbase | 73.2 inches 185 cm |
| Weight | 3869 to 4446 pounds |
| Front tire | 9.5-16 |
| Rear tire | 13.6-24 |
 Full dimensions and tires ... | |
| LS XR4150 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 70 |
| Charging volts | 12 |
| Battery volts | 12 |
| References | |
 | |
| XR4100 Series published in 2015, by LS |
