Yanmar EF330V


No photo available
2005 - 2009
EF300V Series
Compact Utility tractor
EF330
Series:EF328VEF330VEF334V
Production
Manufacturer:Yanmar
Type:Compact Utility tractor
Variants
EF330V:ROPS
EF330VQ:Cab
EF330VJ:ROPS high-speed
EF330VJQ:Cab high-speed
Yanmar EF330V Power
Engine:29.6 hp
22.1 kW
Yanmar EF330V Engine
Yanmar 1.6L 3-cyl diesel
Fuel tank:9.5 gal
36.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Transmission:16-speed four-speed power shift
Transmission details ...
Photos
No photos of the Yanmar EF330V are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:JIS1
Rear lift:3307 lbs
1500 kg
Power Take-off (PTO)
Rear PTO:540 (1.375)
Engine RPM:568@2700
784@2700
991@2700
1296@2700
-623@2700
Dimensions & Tires
Wheelbase:70.9 inches
180 cm
Weight:3230 to 3571 pounds
Front tire:8-16
Rear tire:12.4-26
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
