Yanmar EF330J


Yanmar EF330J tractor photo
2002 - 2004
EF300 Series
Compact Utility tractor
Series:EF328JEF330JEF334J
EF330VJ
Production
Manufacturer:Yanmar
Type:Compact Utility tractor
Variants
EF330:ROPS
EF330Q:Cab
EF330J:High-speed ROPS
EF330JQ:high-speed cab
Yanmar EF330J Power
Engine:29.6 hp
22.1 kW
Yanmar EF330J Engine
Yanmar 1.5L 3-cyl diesel
Fuel tank:9.5 gal
36.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Transmission:20-speed four-speed power shift
Transmission details ...
Photos
No photos of the Yanmar EF330J are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:JIS1
Rear lift:3307 lbs
1500 kg
Power Take-off (PTO)
Rear PTO:540 (1.375)
Engine RPM:568@2700
784@2700
991@2700
1296@2700
-623@2700
Dimensions & Tires
Wheelbase:70.9 inches
180 cm
Weight:3285 to 3638 pounds
Front tire:8-16
Rear tire:12.4-26
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
