Landini Landforce 115

Landini Landforce 115 tractor photo
2016 -
Landforce Series
Utility tractor
Series:Landforce 115Landforce 125
Manufacturer:Landini (a part of Argo)
Type:Utility tractor
Landini Landforce 115 Power
Engine:112 hp
83.5 kW
Landini Landforce 115 Engine
FPT 4.5L 4-cyl diesel
Fuel tank:47.6 gal
180.2 L
Engine details ...
Chassis:4x4 MFWD 4WD
Differential lock:electro-hydraulic front and rear
Cab:Two-post folding ROPS. Cab optional with available air-conditioning.
Transmissions:12-speed mechanical shuttle
 36-speed power shuttle
Transmission details ...
No photos of the Landini Landforce 115 are currently available. To submit yours, email it to Photos may only be used with the permission of the original photographer.
Type:open center
 closed center*Optional
Pressure:2611 psi
180.0 bar
Valves:2 or 3
Pump flow:17.4 gpm
65.9 lpm (open)
 29.1 gpm
110.1 lpm (closed)
Total flow:25.1 gpm
95.0 lpm (open)
 39.1 gpm
148.0 lpm (closed)
Steering flow:7.7 gpm
29.1 lpm (open)
 10 gpm
37.9 lpm (closed)
Tractor hitch
Rear Type:II
Control:position and draft control. Landtronic electric draft control optional.
Rear lift:9900 lbs
4490 kg
Power Take-off (PTO)
Rear PTO:independent
Clutch:electro-hydraulic wet disc
Rear RPM:540/1000 (1.375)
 540/750 (1.375)*Optional
Dimensions & Tires
Wheelbase:100 inches
254 cm
Weight:9240 lbs
4191 kg
Front tire:14.9R24
Rear tire:16.9R38
Full dimensions and tires ...
Battery volts:12
