Landini Landforce 115
|
|
| Production | |
| Manufacturer | Landini (a part of Argo) |
| Utility tractor | |
| Landini Landforce 115 Engine | |
| FPT 4.5L 4-cyl diesel | |
| Fuel tank | 47.6 gal 180.2 L |
 Engine details ... | |
| Landini Landforce 115 Transmissions | |
| 12-speed mechanical shuttle | |
| 36-speed power shuttle | |
 Transmission details ... |
| Landini Landforce 115 Power | |
| Engine | 112 hp 83.5 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | electro-hydraulic front and rear |
| Power steering | |
| Two-post folding ROPS. Cab optional with available air-conditioning. | |
| Photos | |
| No photos of the Landini Landforce 115 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| closed center OptOptional | |
| Pressure | 2611 psi 180.0 bar |
| Valves | 2 or 3 |
| Pump flow | 17.4 gpm (open) 65.9 lpm |
| 29.1 gpm (closed) 110.1 lpm | |
| Total flow | 25.1 gpm (open) 95.0 lpm |
| 39.1 gpm (closed) 148.0 lpm | |
| Steering flow | 7.7 gpm (open) 29.1 lpm |
| 10 gpm (closed) 37.9 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control. Landtronic electric draft control optional. |
| Rear lift | 9900 lbs 4490 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| 540/750 (1.375)OptOptional | |
| Dimensions & Tires | |
| Wheelbase | 100 inches 254 cm |
| Weight | 9240 lbs 4191 kg |
| Front tire | 14.9R24 |
| Rear tire | 16.9R38 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Landforce 115 - 125 published in 2016, by Landini |
