Tractors > CaseIH > Farmall 55C Series II

CaseIH Farmall 55C Series II



CaseIH Farmall 55C Series II tractor photo
2017 -
Farmall C Series
Compact Utility tractor
Series map:
Farmall 45C
Farmall 55C
45.0hp
55.0hp
Production
ManufacturerCaseIH (a part of CNH)
Compact Utility tractor
Original price$36,310 (2020 shuttle ROPS )
$43,362 (2020 hydro Cab )
$49,449 (2025 shuttle ROPS )
$61,513 (2025 hydro Cab )
CaseIH Farmall 55C Engine
LS Mtron 1.9L 3-cyl diesel
ROPS Fuel tank10.6 gal
40.1 L
Cab Fuel tank12.4 gal
46.9 L
Engine details ...
CaseIH Farmall 55C Transmissions
16-speed mechanical shuttle
hydrostatic
Transmission details ...
CaseIH Farmall 55C Power
Engine55 hp
41.0 kW
Gear PTO (claimed)46.7 hp
34.8 kW
Hydro PTO (claimed)44 hp
32.8 kW
Mechanical
Four-wheel drive
Differential lockmechanical rear
Power steering
Wet multi disc brakes
Two-post folding ROPS. Cab optional with air-conditioning.
Photos
No photos of the CaseIH Farmall 55C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Valves1 or 2
Pump flow8.2 gpm
31.0 lpm
Gear Steering flow4.2 gpm
15.9 lpm
Hydro Steering flow5.3 gpm
20.1 lpm
Tractor hitch
Rear TypeI
Controlposition control
Rear lift (at ends)2756 lbs
1250 kg
Rear lift (at 24"/610mm)2469 lbs
1119 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540 (1.375)
Mid PTOindependent OptOptional
Mid PTO Type2000
Dimensions & Tires
Wheelbase73.2 inches
185 cm
Weight3770 to 4453 pounds
Front tire9.5x16
Rear tire13.6x24
Full dimensions and tires ...
CaseIH Farmall 55C attachments
front-end loader
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps70
Battery volts12
References
Farmall 55C Series II references literature
Farmall Compact published in 2019, by CaseIH
Farmall Compact C Series II published in 2019, by CaseIH
