Tractors > John Deere > 5725

John Deere 5725



John Deere 5725 tractor photo
2006 - 2012
5025 Series
Utility tractor
Series map:
5625
5725
60.4kw
66.4kw
Production
ManufacturerJohn Deere
Utility tractor
Built in Saltillo, Mexico
Variants
5725Oorchard
5725HChigh-crop
John Deere 5725 Engine
John Deere 4.6L 4-cyl diesel
OOS Fuel tank25 gal
94.6 L
IOOS Fuel tank37 gal
140.0 L
Cab Fuel tank37 gal
140.0 L
PowrReverser Cab Fuel tank33 gal
124.9 L
Engine details ...
John Deere 5725 Transmissions
9-speed gear
9-speed partially synchronized
12-speed power shuttle
Transmission details ...
John Deere 5725 Power
Engine89 hp
66.4 kW
PTO (claimed)77 hp
57.4 kW
Mechanical
Two- or four-wheel drive
Power steering
Hydraulic wet disc brakes
Two-post fixed ROPS. Foldable ROPS optional. Optional isolate platform (IOOS). Cab optional with air-conditioning.
Photos
No photos of the John Deere 5725 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pressure2800 psi
193.1 bar
Pump flow15.9 gpm
60.2 lpm
Steering flow6.6 gpm
25.0 lpm
Steering press.1900 psi
131.0 bar
Tractor hitch
Rear TypeII/I
Controltop-link draft sensing
Rear lift (at 24"/610mm)3374 lbs
1530 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type540 (1.375)
Engine RPM540@2400
 540E@1700
Dimensions & Tires
Wheelbase85.8 inches
217 cm
Weight5512 to 7130 pounds
Front tire12.4x24
Rear tire18.4x30
Full dimensions and tires ...
5725 Serial Numbers
Location:Serial number plate on the left side of the tractor frame, above the front axle.
Electrical
Groundnegative
Charging systemalternator
ROPS Charging amps70
Cab Charging amps90
Battery CCA550
Battery volts12
Battery Group27F
References
5725 references literature
Tractores Serie 5025 published in 2007, by John Deere
