Iseki TU1701
|
|
| Production | |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Variants | |
| TU1701F | 4WD |
| Iseki TU1701 Engine | |
| Isuzu 1.2L 3-cyl diesel | |
| Fuel tank | 6.1 gal 23.1 L |
 Engine details ... | |
| Iseki TU1701 Power | |
| Engine | 16.8 hp 12.5 kW |
| Mechanical | |
| Two- or four-wheel drive |
| Photos | |
| No photos of the Iseki TU1701 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | JIS0 |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 528@2300 |
| 814@2300 | |
| 1288@2300 | |
| Dimensions & Tires | |
| Wheelbase | 53.2 inches 135 cm |
| Weight | 1543 to 1576 pounds |
| Front tire | 4.00-12 |
| 2WD Rear tire | 8.3-22 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Gold Series published in 1984, by Iseki | |
| TU 1701 1901 2101 |
