Hefty G
|
|
| Production | |
| Manufacturer | Hefty |
| Tool Carrier tractor | |
| Built in Juneau, Wisconsin, USA | |
| Variants | |
| Hi-G | high-crop tractor |
| Hefty G Engine | |
| Continental 0.8L 4-cyl gasoline | |
 Engine details ... |
| Hefty G Transmission | |
| 6-speed gear | |
 Transmission details ... |
| Hefty G Power | |
| Engine | 27 hp 20.1 kW |
| PTO (claimed) | 24 hp 17.9 kW |
| Mechanical | |
| Two-wheel drive | |
| Steering | manual |
| Steering | power OptOptional |
| Mechanical disc brakes | |
| Open operator station. | |
| Photos | |
| No photos of the Hefty G are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pressure | 2000 psi 137.9 bar |
| Valves | 2 |
| Pump flow | 3.2 gpm 12.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Power Take-off (PTO) | |
| Rear PTO | independent OptOptional |
| Rear PTO Type | 540 (1.375) |
| 1000 (1.375) | |
| Mid PTO | independent OptOptional |
| Mid PTO Type | 540 (1.375) |
| 1000 (1.375) | |
| Dimensions & Tires | |
| Wheelbase | 75 inches*Multipile position front axle allows for a wheelbase range of 75 to 89 inches. 190 cm |
| Weight | 2100 lbs 952 kg |
| Front tire | 5.00-15 |
| Rear tire | 9.5-24 |
 Full dimensions and tires ... | |
| Hefty G attachments | |
| 60" mid-mount mower deck | |
| blade | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| G - Implements published by Hefty | |
| G published by Hefty |
