Allis Chalmers 8030 High-Clearance
|
|
Series map:
8010 High-Clearance
8030 High-Clearance
8050 High-Clearance
119.3hp*
148.7hp*
169.3hp*
*Estimated engine power for comparison only.
| Production | |
| Manufacturer | Allis Chalmers |
| High-Clearance tractor | |
| Built in West Allis, Wisconsin, USA | |
| Allis Chalmers 8030 High-Clearance Engine | |
| Allis Chalmers 7.0L 6-cyl diesel | |
 Engine details ... |
| Allis Chalmers 8030 High-Clearance Transmission | |
| 12-speed six-speed power shift | |
 Transmission details ... |
| Allis Chalmers 8030 High-Clearance Power | |
| Drawbar (claimed) | 116.7 hp 87.0 kW |
| PTO (claimed) | 133.8 hp 99.8 kW |
| Mechanical | |
| Two-wheel drive |
| Photos | |
| No photos of the Allis Chalmers 8030 High-Clearance are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 60 gal 227.1 L |
| Hydraulic system | 37 gal 140.0 L |
| Hydraulics | |
| Type | load sensing |
| Capacity | 37 gal 140.0 L |
| Tractor hitch | |
| Rear Type | III/II |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 106 inches 269 cm |
| Front tire | 9.50x20 |
| Rear tire | 18.4x38 |
 Full dimensions and tires ... | |
| References | |
 | |
| High-Clearance 8010/8030/8050 published in 1983, by Allis Chalmers |
