LS XG3135
|
|
| Production | |
| Manufacturer | LS |
| Compact Utility tractor | |
| LS XG3135 Engine | |
| LS 1.9L 3-cyl diesel | |
| Fuel tank | 7.4 gal 28.0 L |
 Engine details ... | |
| LS XG3135 Transmissions | |
| 12-speed sync shuttle | |
| hydrostatic | |
 Transmission details ... |
| LS XG3135 Power | |
| Engine (gross) | 35 hp 26.1 kW |
| Gear PTO (claimed) | 30.1 hp 22.4 kW |
| Hydro PTO (claimed) | 28 hp 20.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the LS XG3135 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | open center |
| Pump flow | 8.2 gpm 31.0 lpm |
| Gear Total flow | 12.3 gpm 46.6 lpm |
| Hydro Total flow | 13.7 gpm 51.9 lpm |
| Gear Steering flow | 4.1 gpm 15.5 lpm |
| Hydro Steering flow | 5.5 gpm 20.8 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift (at ends) | 1808 lbs 820 kg |
| Rear lift (at 24"/610mm) | 1433 lbs 650 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2509 |
| Dimensions & Tires | |
| Wheelbase | 69 inches 175 cm |
| Weight | 2884 lbs 1308 kg |
| Front tire | 7-14 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| LS XG3135 attachments | |
| front-end loader | |
| backhoe | |
 Attachment details ... |
| Electrical | |
| Charging amps | 70 |
| Battery volts | 12 |
| References | |
 | |
| XG3100 Series published in 2016, by LS | |
| XG3135 - XG3135H - XG3135 - XG3135H (52119211/01) published in 2016 |
