Caterpillar D8
|
|
| Production | |
| Manufacturer | Caterpillar |
| Agricultural Crawler tractor | |
| Built in Peoria, Illinois, USA | |
| Variants | |
| D8D | torque converter |
| D8E | direct drive |
| D8G | direct drive |
| D8F | torque converter |
| Caterpillar D8 Engine | |
| Caterpillar 20.4L 6-cyl diesel | |
| Fuel tank | 118 gal 446.6 L |
 Engine details ... | |
| Caterpillar D8 Transmissions | |
| 5-speed gear | |
| 3-speed torque converter | |
 Transmission details ... |
| Caterpillar D8 Power | |
| Engine | 191 hp 142.4 kW |
| Drawbar (claimed) | 155 hp 115.6 kW |
| Drawbar (tested) | 157.58 hp 117.5 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | crawler |
| Open operator station. Cab optional. | |
| Photos | |
| No photos of the Caterpillar D8 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Dimensions & Tracks | |
| Weight | 39060 to 47335 pounds |
| 22-inch tracks | |
 Full dimensions and tracks ... | |
| References | |
 | |
| Farming on the contour published in 1954, by Caterpillar | |
| D8 Tractor Series D and Series E published in 1955, by Caterpillar |
