Kubota M1-85


Kubota M1-85 tractor photo
1988 - 1998
M1 Series
Utility tractor
Series:M1-75M1-85M1-100
Production
Manufacturer:Kubota
Type:Utility tractor
Kubota M1-85 Power
Engine:85 hp
63.4 kW
PTO (claimed):79.9 hp
59.6 kW
Kubota M1-85 Engine
Kubota 4.7L 4-cyl diesel
Fuel tank:27.7 gal
104.8 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Cab:Four-post ROPS. Cab optional.
Transmissions:12-speed
 18-speed creeper
Transmission details ...
Photos
No photos of the Kubota M1-85 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:JIS1
 JIS2
Rear lift:6173 lbs
2800 kg
Power Take-off (PTO)
Rear RPM:540/1000 (1.375)
Engine RPM:540@2035
1000@2389
Dimensions & Tires
Wheelbase:90.6 inches
230 cm
Weight:6570 lbs
2980 kg
Front tire:9.5-24
Rear tire:13.9-36
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
