International Harvester Titan 18-35


International Harvester Titan 18-35 tractor photo
1912 - 1915
Titan Series
Standard-tread tractor
Production
Manufacturer:International Harvester
Type:Standard-tread tractor
Factory:Milwaukee, Wisconsin, USA
International Harvester Titan 18-35 Power
Drawbar (claimed):18 hp
13.4 kW
Belt (claimed):35 hp
26.1 kW
International Harvester Titan 18-35 Engine
International Harvester 16.5L 2-cyl kerosene
Fuel tank:43.75 gal
165.6 L
Aux. fuel:20 gal
75.7 L
Engine details ...
Mechanical
Chassis:4x2 2WD
Steering:manual
Cab:Open operator station with canopy.
Transmission:2-speed gear
Transmission details ...
Photos
No photos of the International Harvester Titan 18-35 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Dimensions & Tires
Weight:15700 to 16850 pounds
Front tire:38x9
Rear tire:63x22
Full dimensions and tires ...
Titan 18-35 Serial Numbers
1912:TC101 (hit-miss)
1913:TC103 (hit-miss)
Final:TC103 (hit-miss)
1913:TB101 (throttle)
1914:TB220 (throttle)
Final:TB238
1914:TF101
1915:TF171
Final:TF218

how to read serial numbers...

Belt Pulley
Diameter:24 inches
60 cm
Width:12.5 inches
31 cm
