Marshall 264
| | 1992 - ???? |
| Compact Utility tractor | | Ferrari built |
|
| Production |
| Distributor: | Marshall
|
| Manufacturer: | Ferrari
|
| Type: | Compact Utility tractor
|
| Marshall 264 Power |
| Engine: | 25.8 hp
19.2 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Differential lock: | mechanical rear
|
| Steering: | manual
|
| Brakes: | mechanical drum
|
| Cab: | Two-post fixed ROPS.
|
| Transmissions: | 6-speed gear
|
| | 12-speed gear
|
 Transmission details ... |
| Photos |
| No photos of the Marshall 264 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | open center
|
| Pressure: | 2400 psi
165.5 bar
|
| Valves: | 2
|
| Pump flow: | 3.2 gpm
12.1 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift (at ends): | 1210 lbs
548 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 540/1000 (1.375)
|
| Engine RPM: | 540@2700
1000@2700
|
| Electrical |
| Ground: | negative
|
| Charging system: | generator
|
| Battery volts: | 12
|
