John Deere 3033R



John Deere 3033R tractor photo
2014 -
3R Series
Compact Utility tractor
Series map:
3033R
3038R
24.5kw
27.7kw
Production
ManufacturerJohn Deere
Compact Utility tractor
John Deere 3033R Engine
Yanmar 1.6L 3-cyl diesel
Engine details ...
John Deere 3033R Transmission
hydrostatic
Transmission details ...
John Deere 3033R Power
Engine (gross)32.8 hp
24.5 kW
Engine (net)31.4 hp
23.4 kW
PTO (claimed)25 hp
18.6 kW
Mechanical
Four-wheel drive
Final drivesspur gear
Differential lockmechanical rear
Power steering
Wet disc brakes
Two-post folding ROPS. Cab optional.
Photos
No photos of the John Deere 3033R are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
ROPS Fuel13.5 gal
51.1 L
Cab Fuel11.9 gal
45.0 L
Hydraulic system6.8 gal
25.7 L
Hydraulics
Typeopen center
Capacity6.8 gal
25.7 L
Pump flow8.6 gpm
32.6 lpm
Total flow13.9 gpm
52.6 lpm
Steering flow5.3 gpm
20.1 lpm
Tractor hitch
Rear TypeI
Rear lift (at ends)2531 lbs
1148 kg
Rear lift (at 24"/610mm)2202 lbs
998 kg
Front Hitch0/I OptOptional
Front lift (at ends)2430 lbs
1102 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchwet disc
Rear PTO Type540 (1.375)
Mid PTOindependent *Standard with hydrostatic, optional with PowrReverser.
Mid PTO Type2100
Front PTOindependent OptOptional
Front PTO Type2100
Dimensions & Tires
Wheelbase68 inches
172 cm
Weight3086 to 3748 pounds
Front tire7.00-14
Rear tire11.2-24
Full dimensions and tires ...
John Deere 3033R attachments
backhoe
Attachment details ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
3033R references literature
Compact Utility Tractors published in 2016, by John Deere
