John Deere 3036E
|
|
| Production | |
| Manufacturer | John Deere |
| Compact Utility tractor | |
| John Deere 3036E Engine | |
| Yanmar 1.5L 3-cyl diesel | |
 Engine details ... |
| John Deere 3036E Power | |
| Engine (gross) | 36.6 hp 27.3 kW |
| Engine (net) | 33.5 hp 25.0 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | spur gear |
| Differential lock | mechanical rear |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. | |
| Photos | |
| No photos of the John Deere 3036E are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 6.3 gal 23.8 L |
| Hydraulic system | 5.5 gal 20.8 L |
| Hydraulics | |
| Type | open center |
| Capacity | 5.5 gal 20.8 L |
| Pressure | 2495 psi 172.0 bar |
| Pump flow | 5.3 gpm 20.1 lpm |
| Total flow | 9.3 gpm 35.2 lpm |
| Steering flow | 4 gpm 15.1 lpm |
| Tractor hitch | |
| Rear Type | I |
| Rear lift | 1356 lbs 615 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | wet disc |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 540@2600 |
| Dimensions & Tires | |
| Weight | 2315 lbs 1050 kg |
| Front tire | 7-14 |
| Rear tire | 11.2-24 |
 Full dimensions and tires ... | |
| John Deere 3036E attachments | |
| front-end loader | |
 Attachment details ... |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| 20C/25C/3036E Standard Compact Utility Tractors published in 2009, by John Deere | |
| 3036E Standard Compact Utility Tractor published in 2010, by John Deere |
