GBT GBT-3000
|
|
| Production | |
| Manufacturer | GBT |
| Utility tractor | |
| Built in Madison, Wisconsin, USA | |
| Original price was $4,650 in 1976 | |
| GBT GBT-3000 Engine | |
| Continental 0.8L 4-cyl gasoline | |
 Engine details ... |
| GBT GBT-3000 Transmission | |
| 6-speed gear | |
 Transmission details ... |
| GBT GBT-3000 Power | |
| Engine | 27 hp 20.1 kW |
| Mechanical | |
| Two-wheel drive | |
| Power steering | |
| Hydraulic disc brakes | |
| Open operator station. |
| Photos | |
| No photos of the GBT GBT-3000 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel | 7.75 gal 29.3 L |
| Hydraulic system | 0.7 gal 2.6 L |
| Hydraulics | |
| Type | open center |
| Capacity | 0.7 gal 2.6 L |
| Pressure | 2000 psi 137.9 bar |
| Pump flow | 8 gpm 30.3 lpm |
| Tractor hitch | |
| Rear Type | I |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 70.5 inches 179 cm |
| Weight | 2500 lbs 1134 kg |
| Front tire | 5.00x15 |
| Rear tire | 12.4x24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| GBT-3000 published in 1976 | |
| GBT-3000 Operator's Manual published in 1976 |
