Iseki AT280


Iseki AT280 tractor photo
2010 - 2012
AT Series
Compact Utility tractor
AT27
Series:AT260AT280AT310
Production
Manufacturer:Iseki
Type:Compact Utility tractor
Variants
AT280:wheeled
AT280C:half-track
Iseki AT280 Power
Engine:27.6 hp
20.6 kW
Iseki AT280 Engine
Iseki 1.6L 3-cyl diesel
Fuel tank:9.25 gal
35.0 L
Engine details ...
Mechanical
Chassis:4x4 MFWD 4WD
Steering:power
Brakes:wet disc
Cab:Two-post ROPS. Cab optional with air-conditioning.
Transmissions:16-speed
 24-speed
Transmission details ...
Photos
No photos of the Iseki AT280 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Tractor hitch
Rear Type:I
Power Take-off (PTO)
Rear RPM:540 (1.375)
Engine RPM:569@2500
765@2500
942@2500
1227@2500
-765@2500
Dimensions & Tires
Wheelbase:66 inches
167 cm
Weight:3020 to 3351 pounds
Front tire:7-16
Rear tire:12.4-24
Full dimensions and tires ...
Electrical
Ground:negative
Battery volts:12
