Claas Axion 950
| | 2011 - 2023 |
|
| Axion 900 Series | | Row-Crop tractor |
|
| Production |
| Manufacturer: | Claas
|
| Type: | Row-Crop tractor
|
| Claas Axion 950 Power |
| Engine (gross): | 399.6 hp
298.0 kW
|
| Engine (max): | 403.7 hp
301.0 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | wet disc
|
| Cab: | Cab standard with air-conditioning.
|
| Transmission: | continuously variable transmission
|
 Transmission details ... |
| Photos |
| No photos of the Claas Axion 950 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type: | load sensing
|
| Valves: | 3 to 8
|
| Pump flow: | 39.6 gpm
149.9 lpm
|
| | 58.1 gpm
219.9 lpm *Optional
|
| Tractor hitch |
| Rear Type: | III/IV
|
| Rear lift (at ends): | 16954 lbs
7690 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Rear RPM: | 1000
|
| | 540E/1000*Optional
|
| | 1000E/1000*Optional
|
| Front RPM: | 1000
|
| Page information |
| Last update: | September 6, 2018
|
| Copyright: | Copyright 2022 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2022 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
