Claas Axion 930
| | 2011 - 2023 |
|
| Axion 900 Series | | Row-Crop tractor |
|
| Production |
| Manufacturer | Claas
|
| Row-Crop tractor |
| Claas Axion 930 Power |
| Engine (gross) | 344.6 hp
257.0 kW
|
| Engine (max) | 350 hp
261.0 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Cab standard with air-conditioning. |
| Photos |
| No photos of the Claas Axion 930 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | load sensing
|
| Valves | 3 to 8
|
| Pump flow | 39.6 gpm
149.9 lpm
|
| | 58.1 gpmOptOptional
219.9 lpm
|
| Tractor hitch |
| Rear Type | III/IV
|
| Rear lift (at ends) | 16579 lbs
7520 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear RPM | 1000
|
| | 540E/1000 OptOptional
|
| | 1000E/1000 OptOptional
|
| Front RPM | 1000
|
| References |
 |
| Axion published in 2020, by Claas |
| Page information |
| Contact: Peter Easterlund |
| Updated on September 6, 2018 |
| Copyright 2022 TractorData LLC |
