Iseki TG6400
|
|
| Production | |
| Manufacturer | Iseki |
| Compact Utility tractor | |
| Built in Japan | |
| Iseki TG6400 Engine | |
| Iseki 1.5L 3-cyl diesel | |
| Fuel tank | 10.6 gal 40.1 L |
 Engine details ... | |
| Iseki TG6400 Transmission | |
| hydrostatic | |
 Transmission details ... |
| Iseki TG6400 Power | |
| Engine (gross) | 38.5 hp 28.7 kW |
| Mechanical | |
| Four-wheel drive | |
| Differential lock | standard |
| Power steering | |
| Wet disc brakes | |
| Two-post folding ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the Iseki TG6400 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Rear valves | 2 |
| Pump flow | 12.6 gpm 47.7 lpm |
| Tractor hitch | |
| Rear Type | I |
| Control | position control |
| Rear lift (at ends) | 2800 lbs 1270 kg |
| Rear lift (at 24"/610mm) | 2535 lbs 1149 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | electro-hydraulic |
| Rear PTO Type | 540 (1.375) |
| Dimensions & Tires | |
| Wheelbase | 69.7 inches 177 cm |
| Weight | 3053 to 3384 pounds |
 Full dimensions and tires ... | |
| Electrical | |
| Charging system | alternator |
| Battery CCA | 582 |
| Battery volts | 12 |
| Battery AH | 55 |
| References | |
 | |
| TG Series Compact Tractors published in 2015, by Iseki | |
| TG Series Compact Tractors published in 2016, by Iseki |
