Challenger MT740
|
|
| Production | |
| Manufacturer | Challenger (a part of AGCO) |
| Agricultural Crawler tractor | |
| Built in Jackson, Minnesota, USA | |
| Challenger MT740 Engine | |
| AGCO Power 9.8L 7-cyl diesel | |
| Fuel tank | 180 gal 681.3 L |
| 215 galOptOptional 813.8 L | |
| 257 galOptOptional 972.7 L | |
| Exhaust fluid (DEF) | 21 gal 79.5 L |
 Engine details ... | |
| Challenger MT740 Transmission | |
| infinitely-variable transmission | |
 Transmission details ... |
| Challenger MT740 Power | |
| Engine (gross) | 400 hp 298.3 kW |
| PTO (claimed) | 310 hp 231.2 kW |
| Drawbar (tested) | 293.03 hp 218.5 kW |
| PTO (tested) | 350.91 hp 261.7 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | crawler |
| Cab standard with air-conditioning. | |
| Photos | |
| No photos of the Challenger MT740 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Hydraulics | |
| Type | load sensing |
| Valves | 4 to 6 |
| Pump flow | 58 gpm 219.5 lpm |
| 116 gpm*With optional dual pumps. 439.1 lpm | |
| Tractor hitch | |
| Rear Type | III/IVN |
| Rear lift | 19000 lbs 8618 kg |
| Dimensions & Tracks | |
| Weight | 33443 lbs 15169 kg |
| Tracks | |
 Full dimensions and tracks ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| References | |
 | |
| MT700 Series published in 2017, by AGCO |
