Kubota KL285
|
|
| Production | |
| Manufacturer | Kubota |
| Compact Utility tractor | |
| Kubota KL285 Engine | |
| Kubota 1.6L 3-cyl diesel | |
| Fuel tank | 9.5 gal 36.0 L |
 Engine details ... | |
| Kubota KL285 Transmissions | |
| 16-speed | |
| 24-speed | |
 Transmission details ... |
| Kubota KL285 Power | |
| Engine | 27.6 hp 20.6 kW |
| Mechanical | |
| Four-wheel drive | |
| Power steering | |
| Mechanical wet disc brakes | |
| Two-post ROPS. Cab optional. |
| Photos | |
| No photos of the Kubota KL285 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type | I |
| Power Take-off (PTO) | |
| Rear PTO Type | 540 (1.375) |
| Engine RPM | 561@2700 |
| 791@2700 | |
| 980@2700 | |
| 1307@2700 | |
| -980@2700 | |
| Dimensions & Tires | |
| Wheelbase | 67.7 inches 171 cm |
| Weight | 2833 to 3285 pounds |
| Front tire | 7-16 |
| Rear tire | 12.4-24 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Battery volts | 12 |
| References | |
 | |
| Operator Manual KL (T01850-1920-1) |
