Kubota GL301
| | 1996 - 2001 |
| GL Series | | Compact Utility tractor |
|
| Production |
| Manufacturer: | Kubota
|
| Type: | Compact Utility tractor
|
| Kubota GL301 Power |
| Engine: | 30.6 hp
22.8 kW
|
| PTO (claimed): | 29.1 hp
21.7 kW
|
| Mechanical |
| Chassis: | 4x4 MFWD 4WD
|
| Steering: | power
|
| Brakes: | mechanical wet disc
|
| Cab: | Two-post ROPS. Cab optional.
|
| Transmissions: | 16-speed gear
|
| | 16-speed power shift
|
 Transmission details ... |
| Photos |
| No photos of the Kubota GL301 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Pump flow: | 5.9 gpm
22.3 lpm
|
| Tractor hitch |
| Rear Type: | I
|
| Rear lift: | 1995 lbs
904 kg
|
| Power Take-off (PTO) |
| Rear RPM: | 537/759/931/1233 (1.375)
|
| Electrical |
| Ground: | negative
|
| Battery volts: | 12
|
| Page information |
| Last update: | September 26, 2017
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Full dimensions and tires ...
