Production | |
Manufacturer: | Massey Ferguson (a part of AGCO) |
Type: | Compact Utility tractor |
Massey Ferguson 1540 Power | |
Engine (gross): | 40.1 hp 29.9 kW |
PTO (claimed): | 31 hp 23.1 kW |
Massey Ferguson 1540 Engine | |
Iseki 1.5L 3-cyl diesel | |
Fuel tank: | 10.6 gal 40.1 L |
Engine details ... |
Mechanical | |
Chassis: | 4x4 MFWD 4WD |
Brakes: | wet disc |
Cab: | Two-post folding ROPS. |
Transmissions: | 8-speed mechanical shuttle |
12-speed mechanical shuttle | |
Transmission details ... |
Photos | |
No photos of the Massey Ferguson 1540 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics | |
Type: | open center |
Rear valves: | 0 to 2 |
Mid valves: | 2 |
Pump flow: | 9.1 gpm 34.4 lpm |
Total flow: | 14 gpm 53.0 lpm |
Steering flow: | 4.9 gpm 18.5 lpm |
Tractor hitch | |
Rear Type: | I |
Control: | position control |
Rear lift (at ends): | 2800 lbs 1270 kg |
Power Take-off (PTO) | |
Rear PTO: | independent |
Clutch: | electro-hydraulic |
Rear RPM: | 540 (1.375) |
Mid PTO: | optional |
Mid RPM: | 2000 |
Dimensions & Tires | |
Wheelbase: | 70 inches 177 cm |
Weight: | 3058 lbs 1387 kg |
Full dimensions and tires ... |
Massey Ferguson 1540 attachments | |
72" mid-mount mower deck | |
snowblower | |
blade | |
front-end loader | |
backhoe | |
Attachment details ... |
Electrical | |
Ground: | negative |
Charging system: | alternator |
Battery volts: | 12 |
