Zetor 11741
| | 2002 - 2007 |
| Forterra Series |
|
Series map:
11441
11741
82.0kw
89.5kw
| Production |
| Manufacturer | Zetor
|
| Built in Brno, Czechoslovakia |
| Zetor 11741 Power |
| Engine | 120 hp
89.5 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | inboard planetary
|
| Differential lock | electro-pneumatic rear
|
| Power steering |
| Hydraulic wet disc brakes |
| Trailer brakes | hydraulic OptOptional
|
| | pneumatic OptOptional
|
| Cab standard with available air-conditioning. |
| Photos |
| No photos of the Zetor 11741 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | open center
|
| Pump flow | 15.6 gpm
59.0 lpm
|
| | 19.3 gpmOptOptional
73.1 lpm
|
| Steering flow | 6 gpm
22.7 lpm
|
| Tractor hitch |
| Rear Type | II/I
|
| Control | position control and lower-link draft sensing
|
| Rear lift | 13150 lbs
5964 kg
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Clutch | wet disc
|
| Rear PTO Type | 540/1000 (1.375)
|
| Electrical |
| Ground | negative
|
| Charging system | alternator
|
| Charging amps | 70
|
| Battery CCA | 800
|
| Battery volts | 12
|
| References |
 |
| Forterra Series Tractors published in 2004, by Zetor |
| Page information |
 |
| Copyright 2025 TractorData.com® |
| Email me: Peter@TractorData.com |
| TractorData is a family-owned small business located in Minnesota. I have been researching tractor history and providing specifications for free since 1999. |
| Peter Easterlund - owner/author |
| This machine's data modified on November 30, 2025 |
