Zetor Proxima Power 100
| 2010 - 2016 |
|
Proxima Series | Utility tractor |
|
Production |
Manufacturer: | Zetor
|
Type: | Utility tractor
|
Factory: | Brno, Czech Republic
|
Zetor Proxima Power 100 Power |
Engine (net): | 96 hp 71.6 kW
|
Mechanical |
Chassis: | 4x4 MFWD 4WD
|
Differential lock: | electro-pneumatic
|
Steering: | power
|
Brakes: | hydraulic wet disc
|
Trailer brakes: | pneumatic
|
| hydraulic*Optional
|
Cab: | Cab standard with optional air-conditioning.
|
Transmission: | 24-speed three-speed power shift
|
Transmission details ... |
Photos |
No photos of the Zetor Proxima Power 100 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
Hydraulics |
Pressure: | 2756 psi 190.0 bar
|
Valves: | 3
|
Total flow: | 13.2 gpm 50.0 lpm
|
Tractor hitch |
Rear Type: | II
|
Control: | position control and mechanical top-link draft sensing
|
Rear lift: | 9442 lbs 4282 kg
|
Power Take-off (PTO) |
Rear PTO: | independent
|
Clutch: | wet disc
|
Rear RPM: | 540/1000
|
| 540/540E
|
Front RPM: | 1000
|
Electrical |
Charging system: | alternator
|
