Oliver 1550 Row Crop Utility
|
|
| Production | |
| Manufacturer: | Oliver |
| Type: | Utility tractor |
| Factory: | Charles City, Iowa, USA |
| Variants | |
| Row-crop: | tricycle front, single front, or adjustable wide front |
| Wheatland: | standard front |
| Utility: | low-clearance |
| Oliver 1550 Row Crop Utility Power | |
| Gas PTO (claimed): | 53 hp 39.5 kW |
| Diesel PTO (claimed): | 53 hp 39.5 kW |
| LP-gas PTO (claimed): | 51 hp 38.0 kW |
| Oliver 1550 Row Crop Utility Engines | |
| Oliver 3.8L 6-cyl diesel | |
| Oliver 3.8L 6-cyl gasoline | |
| Oliver 3.8L 6-cyl LP-gas | |
| Gas Fuel tank: | 27.5 gal 104.1 L |
| Diesel Fuel tank: | 27.5 gal 104.1 L |
| LP-gas Fuel tank: | 34 gal 128.7 L |
| 78 gal 295.2 L *Capacity of optional fender fuel tanks. | |
 Engine details ... | |
| Mechanical | |
| Chassis: | 4x2 2WD |
| Steering: | power assist |
| Brakes: | disc |
| Cab: | Open operator station. Oliver Continental cab optional. |
| Transmissions: | 12-speed partial power shift |
| 6-speed unsynchronized gear | |
 Transmission details ... | |
| Photos | |
| No photos of the Oliver 1550 Row Crop Utility are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Tractor hitch | |
| Rear Type: | II/I |
| Control: | lower-link draft sensing |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Rear RPM: | 540 |
| 1000 | |
| 540/1000 | |
| Dimensions & Tires | |
| Wheelbase: | 84.375 inches 214 cm |
| Weight: | 6841 lbs 3103 kg |
| Front tire: | 5.50-16 |
| Rear tire: | 14.9-28 |
 Full dimensions and tires ... | |
| 1550 Row Crop Utility Serial Numbers | |
| 1965: | 157841 |
| 1966: | 168919 |
| 1967: | 184488 |
| 1968: | 196301 |
| 1969: | 213243 |
| Final: | 218186 |
