New Holland T8.435 SmartTrax


New Holland T8.435 SmartTrax tractor photo
2015 -
T8 Series
Half-track Crawler tractor
Series:T8.410 SmartTraxT8.435 SmartTrax
Production
Manufacturer:New Holland
Type:Half-track Crawler tractor
Original price:$430,826 (2016 )
Variants
T8.435:wheeled tractor
T8.435 SmartTrax:half-track
New Holland T8.435 SmartTrax Power
Engine (gross):380 hp
283.4 kW
Engine (max):435 hp
324.4 kW
PTO (claimed):315 hp
234.9 kW
Drawbar (tested):252.66 hp
188.4 kW
PTO (tested):321.73 hp
239.9 kW
power test details ...
New Holland T8.435 SmartTrax Engine
FPT 8.7L 6-cyl diesel
Fuel tank:163 gal
617.0 L
Exhaust fluid (DEF):26 gal
98.4 L
Engine details ...
Mechanical
Chassis:half-track
Final drives:inboard planetary
Brakes:wet disc
Cab:Cab standard with air-conditioning. Intellisteer ready
Transmission:continuously variable transmission (CVT)
Transmission details ...
Photos
No photos of the New Holland T8.435 SmartTrax are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Type:closed center pressure-flow compensating (PFC)
Valves:4 to 5
Pump flow:43 gpm
162.8 lpm
 73 gpm
276.3 lpm *Optional, MegaFlow rate.
Tractor hitch
Rear Type:III/IIIN
 IVN/III
Control:electronic lower-link draft sensing
Rear lift:19900 lbs
9026 kg
Drawbar:Cat. 4
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:1000
 540/1000*Optional
Front PTO:independent*Optional
Front RPM:1000 (1.375)
Dimensions & Tires
Wheelbase:140 inches
355 cm
Weight:35788 lbs
16233 kg
Front tire:380/80R42
Rear tire:18-inch
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:200
Batteries:2
Battery volts:12
