Challenger MT965E
|
|
| Production | |
| Manufacturer | Challenger (a part of AGCO) |
| Four-wheel Drive (4WD) tractor | |
| Built in Jackson, Minnesota, USA | |
| Challenger MT965E Engine | |
| AGCO Power 16.8L 12-cyl diesel | |
| Fuel tank | 400 gal 1514.0 L |
| Exhaust fluid (DEF) | 52 gal 196.8 L |
 Engine details ... | |
| Challenger MT965E Transmission | |
| 16-speed power shift | |
 Transmission details ... |
| Challenger MT965E Power | |
| Engine | 550 hp 410.1 kW |
| PTO (claimed) | 425 hp 316.9 kW |
| Mechanical | |
| Four-wheel drive | |
| Final drives | inboard planetary |
| Differential lock | electro-hydraulic |
| Articulated power steering | |
| Hydraulic wet disc brakes | |
| Pinnacle View Cab standard with air-conditioning. Auto-Guide 3000; AgCommand | |
| Photos | |
 | |
 Challenger MT965E photos... | |
| Hydraulics | |
| Type | closed center pressure-flow compensated |
| Pressure | 2900 psi 200.0 bar |
| Valves | 4 to 6 |
| Pump flow | 58 gpm 219.5 lpm |
| 85 gpmOptOptional 321.7 lpm | |
| SCV flow | 37 gpm 140.0 lpm |
| Tractor hitch | |
| Rear lift | 19500 lbs 8845 kg |
| Drawbar | Cat. 5 |
| Cat. 4 OptOptional | |
| Dimensions & Tires | |
| Weight | 47500 lbs 21546 kg |
| Front tire | 710/70R42 |
| Rear tire | 710/70R42 |
 Full dimensions and tires ... | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| Charging amps | 300 *Twin 150A alternators. |
| Batteries | 4 |
| Battery volts | 12 |
| References | |
 | |
| MT900E Series Articulated Tractors published in 2015, by Challenger |
