Fendt 714 Vario
| | 2006 - 2022 |
|
| 700 Vario Series | | Row-Crop tractor |
|
| Production |
| Manufacturer | Fendt (a part of AGCO)
|
| Row-Crop tractor |
| Fendt 714 Vario Power |
| Engine (gross) | 144 hp
107.4 kW
|
| Engine (net) | 128 hp
95.4 kW
|
| Engine (max) | 150 hp
111.9 kW
|
| Mechanical |
| Four-wheel drive |
| Final drives | planetary
|
| Power steering |
| Wet disc brakes |
| VisioPlus cab standard with air-conditioning and pneumatic suspension. Variotronic; VarioGuide optional |
| Photos |
| No photos of the Fendt 714 Vario are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. |
| Hydraulics |
| Type | load sensing
|
| Pressure | 2901 psi
200.0 bar
|
| Rear valves | 2 to 5
|
| Front valves | 0 to 2
|
| Pump flow | 28.8 gpm
109.0 lpm
|
| | 40.2 gpm*Standard on Profi and ProfiPlus.
152.2 lpm
|
| | 51 gpm*Optional on Profi and ProfiPlus.
193.0 lpm
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear RPM | 540/540E/1000/1000E
|
| Front RPM | 1000
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 200
|
| Charging volts | 14
|
| Battery volts | 12
|
| Battery AH | 180
|
| References |
 |
| 700 Vario published in 2015, by Fendt |
