Mahindra 1538
| | 2016 - 2018 |
| 1500 Series | | Compact Utility tractor | | Mitsubishi built |
|
Series map:
1533
1538
34.5hp
38.7hp
| Production |
| Distributor | Mahindra
|
| Manufacturer | Mitsubishi
|
| Compact Utility tractor |
| Original price | $23,490 (2016 shuttle ROPS )
|
| $24,480 (2016 hydrostatic ROPS )
|
| $32,468 (2016 hydrostatic cab )
|
| Mahindra 1538 Power |
| Engine | 38.7 hp
28.9 kW
|
| Shuttle PTO (claimed) | 29.9 hp
22.3 kW
|
| Hydro PTO (claimed) | 27.7 hp
20.7 kW
|
| Mechanical |
| Four-wheel drive |
| Power steering |
| Wet disc brakes |
| Two-post foldable ROPS. Cab optional with air-conditioning. |
| Hydraulics |
| Type | open center
|
| Rear valves | 1 OptOptional
|
| Pump flow | 7.7 gpm
29.1 lpm
|
| Steering flow | 3.4 gpm
12.9 lpm
|
| Tractor hitch |
| Rear Type | I
|
| Control | position control
|
| Rear lift | 2646 lbs
1200 kg
|
| Rear Arms | telescopic stabilizers
|
| Power Take-off (PTO) |
| Rear PTO | independent
|
| Rear PTO Type | 540 (1.375)
|
| Engine RPM | 540@2376
|
| Mid PTO Type | 2000
|
| Engine RPM | 2000@2525
|
| Electrical |
| Charging system | alternator
|
| Charging amps | 90
|
| Charging volts | 12
|
| Battery volts | 12
|
| Battery AH | 46
|
| Page information |
 |
| Copyright 2024 TractorData.com® |
| TractorData is a family-owned small business located in Minnesota that has been providing reference information on tractors since 1999. |
| Peter Easterlund - owner/author |
| Email: Peter@TractorData.com |
| Updated on December 24, 2023 |
©2000-2024 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
