Ford 276
| | 1988 - 1990 |
| Versatile built |
|
| Production |
| Distributor: | Ford
|
| Manufacturer: | Versatile
|
| Factory: | Winnipeg, Manitoba, Canada
|
| Ford 276 Power |
| Engine: | 116 hp
86.5 kW
|
| PTO (claimed): | 100 hp
74.6 kW
|
| Mechanical |
| Chassis: | 4x4 4WD
|
| Steering: | articulated power
|
| Brakes: | hydraulic disc
|
| Cab: | Cab standard.
|
| Transmission: | hydrostatic
|
 Transmission details ... |
| Hydraulics |
| Type: | closed center load sensing
|
| Pressure: | 2800 psi
193.1 bar
|
| Valves: | 3
|
| Front valves: | 2*Optional
|
| Pump flow: | 27 gpm
102.2 lpm
|
| Steering flow: | 5 gpm
18.9 lpm
|
| Steering press.: | 2300 psi
158.6 bar
|
| Tractor hitch |
| Rear Type: | II/I
|
| Control: | position control
|
| Rear lift (at ends): | 7000 lbs
3175 kg
|
| Rear lift (at 24"/610mm): | 4400 lbs
1995 kg
|
| Front Hitch: | II/I
|
| Front lift (at ends): | 3266 lbs
1481 kg
|
| Front lift (at 24"/610mm): | 2000 lbs
907 kg
|
| Power Take-off (PTO) |
| Rear PTO: | independent
|
| Clutch: | wet disc
|
| Rear RPM: | 540/1000 (1.375)
|
| Front RPM: | 540 (1.375)
|
| | 1000 (1.375)
|
| Engine RPM: | 540@2500
1000@2500
|
| Electrical |
| Ground: | negative
|
| Charging system: | alternator
|
| Battery CCA: | 850
|
| Battery volts: | 12
|
| Page information |
| Last update: | May 19, 2016
|
| Copyright: | Copyright 2021 TractorData LLC
|
| Contact: | Peter@TractorData.com
|
©2000-2021 - TractorData.com®. Notice: Every attempt is made to ensure the data listed
is accurate. However, differences between sources, incomplete listings,
errors, and data entry mistakes do occur.
Consult official
literature from the manufacturer before attempting any service or repair.
Engine details ...
Ford 276 photos...
